Checkweighing System ::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::
Channelizers can solve many material handling issues when sorting or classifying is required. Products are directed or divided into as many as five lanes. Thermo Scientific channelizers are designed for trouble-free operation and easy integration.
Channel cartons, bags, bottles, cans, trays, boards and foods so that case packers, wrappers and freezers operate without overload.
●
Channelizers
PLC-based pattern-forming controls provide for balanced or unbalanced count to multiple lanes. Automatic lane switching controls handle surge or product back-up conditions.
●
Carrier Rejects
Carrier Rejects receive signals from inspection devices and separate products into as many as five lines based on weight classification or other product characteristics. This reject style is particularly useful when dealing with products such as ready-meals where spillage is a concern with conventional reject devices.
Available options include full washdown capability and a wide variety of options to ensure smooth product handling.
Three models of Channelizers and Carrier Rejects are available to serve Standard-Duty, Medium-Duty or Heavy-Duty line dividing needs.
General Purpose Checkweighers (ACCUSTAR)
The Thermo Scientific ACCUSTAR powered weigh table designed with finite analysis offers an open, modular design with superior weighing properties. The unique dual loadcell reduces vibration, improves temperature compensation and increases stability.
Thermo Scientific offers a complete line of checkweighing equipment for efficient product inspection to protect your brand and ensure safety and quality to customers.
●
Rigid construction for superior weighing properties
●
Unique medium-duty dual loadcell with weightable mounts reduces vibration, offers better side loading protection and stability, and improves accuracy and temperature concentration
●
Individual AC or DC motors for each conveyor, allowing for independent speed adjustment, requiring fewer spare parts and no cumbersome drive arrangement
●
Quick-change connectors minimize change time and allow for tool-free removal of conveyors
●
Flip-up tail pulley makes cleaning and maintenance easy
●
Fiber optic photo eye permits simple installation and replacement
●
Conveyors have fully crowned rollers for better tracking and a solid side frame for a more pleasing, cleaner look; with fewer moving parts, there is less maintenance and less downtime
●
Variable Speed Display (VSD) eliminates the need for handheld tachometers normally used to set and check motor speed
Large Case and Bag Checkweigher - Frame 44 and Box-series
The tough and sturdy construction of this frame makes it ideally suited for rugged industrial environments. Standard units are capable of handling line rates of up to 100 packages per minute (i.e., 300 FPM) depending on package length. Excels at accurate weighing at the highest speeds with the largest range of package dimensions; weightable lengths up to 96 in. and speeds to 550 ft./min. position.
●
Includes microprocessor-based electronic control and heavy duty weighframe
●
Rugged design of the weighframe ensures reliability and maintenance-free operation
●
Weightable is virtually damage proof with overload protection up to 1000 lb.
Available with Versa controller. The AC4000WH delivers highly intuitive and easy-to-use controls. Weight data output can be configured into a variety of industry standard formats and optionally integrated with a cubing/dimensioning system for a total shipping inspection solution.
Teorema Can Checkweigher
The Thermo Scientific Teorema checkweigher provides the new standard in high-rate can weighing by combining rugged capability with and accuracy.
Standard Teorema is configured as a turnkey package.
●
Designed with side-to-side conveyor transfer capability at the in-feed and out-feed
●
Photo-eyes to provide controlled feed of cans via a can-stop
Open design and stainless steel construction facilitate high pressure cleaning
●
Electronics automatically monitor temperature and humidity to avoid heat and moisture concerns
Additional Features:
●
No moving parts weigh-section (no chains or belts) for high accuracy and minimum maintenance requirement.
●
Complete systems with the highest levels of safety guarding and interlock included in a single turnkey proposal.
●
Speeds to 660 cans/min.
●
Open or closed cans
●
2-piece or 3-piece cans
●
Steel or aluminum cans
●
As standard, specified for the highest levels of washdown and humidity, typical of the canning industry
●
As standard, equipped with the top of the line AC9000-plus checkweigher controller
Versa 8120 Chain Checkweigher
Thermo Scientific Versa 8120 provides the ultimate in checkweighing performance for high-speed weighing of packaged goods.
●
Rugged chain design is easy to clean and to maintain
●
Open design minimizes product build-up and facilitates cleaning
●
Durable weighframe features a low-maintenance drive system .
●
Simplified design and minimal number of moving parts greatly reduces vibration, allowing for superior accuracy and performance
●
Line speeds up to 700 packages per minutes
●
Easy-to-read, color interface with touch-screen operation
●
Configurable security-access levels
●
One hundred standard product memories, expandable and searchable by product or name
●
Large, high-visibility weight display supplemented by a bright "good/bad" or go/no "go" indicator
●
Versa 8120 is available in a stand-alone pedestal version or with a standard, integrated conveyor
●
As an option for increased functionality, the Versa 8120 infeed conveyor can be fitted with peripheral equipment such as a helix system for cans
●
An optional Thermo Scientific APEX metal detector can be added for a complete weight control and contaminant inspection station
Versa Frame 44 Heavy-Duty Checkweigher
Thermo Scientific Versa Frame 44 checkweighers are engineered for true in-motion weighing—that means it will accurately weigh a wide variety of packages without stopping the conveyor for recalibration. This flexibility guarantees that you'll experience maximum productivity at all times. In addition, the Versa Frame 44 comes with a USDA/FDA approved food grade belt—making it the ideal choice for transferring raw or frozen products, bags, cases or barrels. This checkweigher is also available with optional infeed spacing belts and discharge conveyors in addition to reject devices, visual and audible alarms.
●
Dependable and accurate on-line weighing of packages up to 110 lbs
●
Ideally suited for rugged industrial environments
●
Tough and sturdy construction for heavier and larger products
●
Available in special sizes like XL and XXL
●
USDA/FDA approved food-grade belt.
●
Easy to use electronics—color, touch-screen HMI gives you the control you need at your fingertips
